The present invention relates to a kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component, belong to Relay Protection Technology in Power System field.The present invention is after the distribution network generation singlephase earth fault of neutral by arc extinction coil grounding, line selection apparatus starts, first calculate the absolute value of each feeder line zerosequence current sum in short timewindow after a failure, realize the judgement to busbar fault and feeder fault by this value and the magnitude relationship of setting threshold values; When being defined as feeder fault, then build each feeder line zerosequence current matrix and principal component analysis (PCA) is carried out to it, obtain each Principal component of zerosequence current matrix, and respectively the sign function of the sign function of each for first principal component element and first principal component each symbol of element function sum is taken advantage of; Finally reliably realize failure line selection according to the magnitude relationship of this value and null value.Invention increases accuracy and the reliability of route selection.
Description
Technical field
The present invention relates to a kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component, belong to Relay Protection Technology in Power System field.
Background technology
Power distribution network broad covered area, and directly in the face of user provides power supply service for it.80% of distribution network failure is accounted for according to statistics singlephase earth fault.Power distribution network resonant earthed system is neutral by arc extinction coil grounding system, belongs to small current neutral grounding system.Small current neutral grounding system breaks down and can affect healthy phases voltagetoground and cause it and raise, and voltage raises to produce the insulation of grid equipment and destroys; Particularly intermittent arcing ground, arc overvoltage can be caused, this voltage is by destroying system insulation and then developing into alternate or multipoint earthing short circuit, cause system overvoltage, thus damage equipment, destroy system safety operation, therefore must find faulty line accurately, fast and timely fault to be got rid of.
Distribution network failure mostly is singlephase earth fault, if fault applies power frequency steadystate quantity colony amplitude comparison phase comparing method after occurring carry out route selection, due to the impact by arc suppression coil compensation effect, ground current is faint, may cause route selection mistake.And after fault, fault transient state current amplitude, much larger than steadystate current, and not to affect by arc suppression coil, therefore utilizes the selection method of the selection method Billy steadystate quantity of transient to have more advantage.Recent domestic emerges in multitude based on the achievement in research of transient route selection, but it is to be solved and perfect to still have some problems to have, its main cause is: 1, failure boundary is complicated, random, as fault prima facies angle size, fault distance, transition resistance size etc., different faults condition, the distribution of transient zerosequence signal frequency composition, attenuation characteristic, spectrum energy has larger difference; When 2, there is singlephase earth fault near voltage over zero, the high fdrequency component caused is very little, and the sensitivity of high frequency transient amount selection method is declined greatly; 3, cable line and overhead transmission line electrical specification differ greatly, and perfect similarity between circuit zero sequence current waveform and reduce; 4, adopt traveling wave detector method, row velocity of wave propagation is very fast, and distribution network line is shorter, and power distribution network signal disturbing is more in addition, and row ripple Mintrop wave head not easily reliably catches.
Principal component analysis (PCA) (Principalcomponentsanalysis, PCA) is inferior to proposition in 1901 by Ka Er Pierre, for analyzing data and setting up mathematical model.Its method mainly by carrying out feature decomposition to covariance matrix, with the weights (i.e. eigenwert) of the major component (i.e. proper vector) drawing data with them.The method has been widely used in analysis and the simplification of data set.By the data set of principal component analysis (PCA), its dimension is reduced, but maintains data to the maximum feature of variance contribution.
After neutral by arc extinction coil grounding system generation singlephase earth fault, transient information dissimilar is in a large number contained in its fault transient zerosequence current, namely the dimension of data set is very large, if utilize PCA to extract zerosequence current major component, the feature of main signal is kept while reducing data dimension, realize failure line selection according to this, will effectively reduce the impact of undesired signal, improve the reliability of selection method.By this, a kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component is proposed.
Summary of the invention
Technical matters to be solved by this invention be overcome that traditional selection method is disturbed signal when ground current is faint affect the not high problem of route selection reliability, provide a kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component.
Technical scheme of the present invention is: a kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component, after the distribution network generation singlephase earth fault of neutral by arc extinction coil grounding, line selection apparatus starts, first calculate the absolute value of each feeder line zerosequence current sum in short timewindow after a failure, realize the judgement to busbar fault and feeder fault by this value and the magnitude relationship of setting threshold values; After being defined as feeder fault, then build each feeder line zerosequence current matrix and principal component analysis (PCA) is carried out to it, obtain each Principal component of zerosequence current matrix, and respectively the sign function of the sign function of each for first principal component element and first principal component each symbol of element function sum is taken advantage of; Finally reliably realize failure line selection according to the magnitude relationship of this value and null value.
The concrete steps of described selection method are as follows:
After A, generation singlephase earth fault, in short timewindow, calculate the absolute value of each feeder line zerosequence current sum
i _{∑}, and by this value and setting threshold values
i _{set}magnitude relationship realize to busbar fault and feeder fault judgement:
（1）
When
i _{∑}>
i _{set}time, be judged to be busbar fault;
When
i _{∑}<
i _{set}time, be judged to be feeder fault;
In formula:
i _{0
j }(
k) represent be numbered
jits zerosequence current of feeder line exist
kamplitude during sampled point,
j=1,2,3
nfor the numbering of feeder line,
nfor feeder line number;
k=1,2,3
kfor sampled point numbering,
kfor zerosequence current data sampled point quantity;
k<
n;
B, basis
nbar feeder line is abovementioned
kzerosequence current data on individual zerosequence current data sampled point, builds
n×
kzerosequence current matrix
i, and after principal component analysis (PCA) is carried out to it, the sign function of the sign function and first principal component each symbol of element function sum that obtain each element of first principal component be respectively sgn (
p _{1}(
j)), sgn (∑ sgn (
p _{1}(
j))); Wherein
p _{1}(
j) be the first principal component value after zerosequence current matrix principal component analysis (PCA),
j=1,2,3
nfor the numbering of feeder line,
nfor feeder line number:
（2）
C, according to sgn (
p _{1}(
j)) and sgn (∑ sgn (
p _{1}(
j))) magnitude relationship determination failure line selection between product between the two and null value:
When sgn (
p _{1}(
j)) × sgn (∑ sgn (
p _{1}(
j))) <0 time, judge the
jbar feeder line is fault feeder.
When calculating each feeder line zerosequence current sum, the length of short timewindow is 0.4ms.
Principle of work of the present invention is:
For the distribution network of resonance grounding, in the transient state process after fault occurs, its each bar feeder line zerosequence current is not by the impact of arc suppression coil compensation.If feeder line breaks down, each feeder line zerosequence current amplitude sum that perfects equals fault feeder zerosequence current, and namely all feeder line zerosequence current sums are close to zero; If bus breaks down, each feeder fault zerosequence current is changed direction unanimously in a timing window inwardly projecting, and its zerosequence current sum is much larger than zero.Therefore, when bus residual voltage instantaneous value is outoflimit, namely
u _{ n }(
t) >
k _{ u } u _{ n }time, (wherein:
u _{ n }(
t) be the instantaneous value of bus residual voltage,
u _{ n }for bus rated voltage,
k _{ u }=1.15), be considered as distribution network systems and break down, fault line selection device starts immediately and records ripple, obtains each bar feeder line zero sequence transient current, then can according to zerosequence current in each feeder line after a failure short timewindow and the size of absolute value
judge whether bus there occurs fault (in formula:
i _{0
j }(
k) represent be numbered
jits zerosequence current of feeder line exist
kamplitude during sampled point,
j=1,2,3
nfor the numbering of feeder line,
nfor feeder line number;
k=1,2,3
kfor sampled point numbering,
kfor zerosequence current data sampled point quantity.Consider the impact of outofbalance current, a threshold values is set for specific distribution system
i _{set},
i _{set}obtained by a large amount of emulation.According to the known busbar fault criterion of abovementioned analysis be: when
i _{Σ}>
i _{set}time, busbar fault; When
i _{Σ}<
i _{set}time, feeder fault).
After being judged to be feeder fault, need judging the numbering of fault feeder, thus realize failure line selection.Need to build zerosequence current matrix to carry out principal component analysis (PCA), due to the principal component analysis (PCA) requirement being greater than columns that usually requires analyzed matrix must meet line number, when therefore building matrix of elements, the number of zerosequence current sampled point must be less than the number of distribution network systems feeder line.
Principal component analysis (PCA) original sample data is projected in a new coordinate space, in new coordinate space, the dimension of sample data decreased more originally, the standard constructing new coordinate space is that the every one dimension variance making original sample data in new coordinate space all reaches maximal value, and the projection of each sample data in new coordinate axis is exactly the Principal component under the corresponding dimension of this coordinate axis.After principal component analysis (PCA), low order composition remains the most important information of data, and after therefore carrying out principal component analysis (PCA) to its zerosequence current during distribution network systems feeder fault, the spatial data under first principal component (lowestorder dimension) maintains the topmost feature of zerosequence current.First principal component value is then the projection value of zerosequence current data in new coordinate system in minimum dimension (coordinate axis).When distribution network systems feeder line breaks down, the polarity of fault feeder zerosequence current is contrary in a timing window with the polarity perfecting feeder line zerosequence current, therefore the projection of zerosequence current value under new coordinate must be reflected as wherein with other be distributed in the positive and negative both sides of new coordinate axis a little respectively.Therefore failure line selection can be realized according to this feature.Principal component analysis (PCA) follows these steps to carry out:
Step one: raw data standardization, supposes that the zerosequence current matrix be made up of each bar feeder line zerosequence current is
i _{ ij }, in order to eliminate the different and excessive impact brought of numerical value difference of dimension due to variable, by following formula, standardization is done to former variable:
（3）
Wherein:
;
;
In formula: subscript
ifor feeder line numbering (line label of matrix),
nfor feeder line number (line number of matrix); Subscript
jfor the sampled point of zerosequence current is numbered (matrix column label),
kfor zerosequence current data length (matrix column number).
Step 2: set up correlation matrix
, and calculate the proper vector of its eigenwert.
（4）
In formula:
i ^{*}for the data matrix after standardization, upper table
trepresent transpose operation,
nfor feeder line number (line number of matrix); Try to achieve
reigenwert be
>=
>=
with the unitization proper vector of its correspondence be
v _{1},
v _{2}...,
v _{ k },
k∈
z.
Step 3: determine major component number, first calculate variance contribution ratio:
（5）
In formula:
for correlation matrix
reigenwert,
i=1,2,3
k,
k∈
z.
Then accumulative variance contribution ratio is calculated:
（6）
Accumulative variance contribution ratio is depended in choosing of major component number, and accumulative variance contribution ratio should be greater than 85 ~ 90 usually, before corresponding
individual major component just comprises
most information that individual original variable can provide, therefore determine that the number of major component is
.
Step 4: solve the matrix obtaining major component and form,
pindividual major component characteristic of correspondence vector is
v _{m × p}, then
individual sample
pthe matrix that individual major component is formed
p _{n × p}for:
（7）
Wherein:
v _{k × p}=[
v _{1},
v _{2}...,
v _{ p }];
In formula:
i ^{*}for the data matrix after standardization,
pfor major component number,
m=1,2,3
k,
k∈
z,
for feeder line number,
kfor zerosequence current data length.
Build each feeder line zerosequence current matrix and after principal component analysis (PCA) is carried out to it (wherein first principal component can reflect the feature of zerosequence current), obtain each element of first principal component sign function sgn (
p _{1}(
j)) with the sign function sgn of first principal component each symbol of element function sum (∑ sgn (
p _{1}(
j))), then according to sgn (
p _{1}(
j)) and sgn (∑ sgn (
p _{1}(
j))) magnitude relationship determination failure line selection between product between the two and null value: when sgn (
p _{1}(
j)) × sgn (∑ sgn (
p _{1}(
j))) <0 time, judge the
jbar feeder line be fault feeder (wherein
p _{1}(
j) be the first principal component value after zerosequence current matrix principal component analysis (PCA),
j=1,2,3
nfor the numbering of feeder line,
nfor feeder line number).
The invention has the beneficial effects as follows:
1, this method is before carrying out route selection to fault feeder, has in fact carried out primary election to busbar fault, and specific aim carries out primary election to busbar fault, improves the reliability of route selection.
2, this method is using the element value symbol of first principal component as route selection criterion, reduces the interference of other signals, further increases route selection reliability.
3, the algorithm maturation of principal component analysis (PCA) makes the theory support of this method more solid, and realization rate is more convenient.
Accompanying drawing explanation
Fig. 1 is the distribution network systems realistic model of the neutral by arc extinction coil grounding of the embodiment of the present invention 1 and embodiment 2;
Fig. 2 is the route selection process flow diagram of the embodiment of the present invention 1 and embodiment 2;
Feeder line in window when Fig. 3 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{1}zerosequence current oscillogram;
Feeder line in window when Fig. 4 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{2}zerosequence current oscillogram;
Feeder line in window when Fig. 5 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{3}zerosequence current oscillogram;
Feeder line in window when Fig. 6 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{4}zerosequence current oscillogram;
Feeder line in window when Fig. 7 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{5}zerosequence current oscillogram;
Feeder line in window when Fig. 8 is 0.4ms after the embodiment of the present invention 1 fault occurs
l _{6}zerosequence current oscillogram;
Feeder line in window when Fig. 9 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{1}zerosequence current oscillogram;
Feeder line in window when Figure 10 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{2}zerosequence current oscillogram;
Feeder line in window when Figure 11 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{3}zerosequence current oscillogram;
Feeder line in window when Figure 12 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{4}zerosequence current oscillogram;
Feeder line in window when Figure 13 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{5}zerosequence current oscillogram;
Feeder line in window when Figure 14 is 0.4ms after the embodiment of the present invention 2 fault occurs
l _{6}zerosequence current oscillogram.
Embodiment
Embodiment 1: be illustrated in figure 1 the distribution that 6 feed out the 35kV neutral by arc extinction coil grounding of circuit composition, the G in this electrical network is infinitely great power supply; T is maintransformer, and noload voltage ratio is 110kV/35kV, and connection set is YN/d11; China's power distribution network maintransformer distribution voltage side is generally triangle junction, and system does not exist neutral point, need obtain for the neutral point of grounding through arc, can set up the way that grounding transformer is exactly the best, T herein when system adopts during resonance neutral grounding
_{z}for the special zigzag transformer of compensation network ground connection; L is arc suppression coil, and R is the damping resistance of arc suppression coil.Circuit adopts overhead transmission line, overhead linecable hybrid line and cable line three kinds of circuits, and the numbering of six feeder lines is followed successively by
l _{1},
l _{2},
l _{3}...
l _{6}, wherein,
l _{1}for pole line, length is 15km;
l _{2}for cable, length is 6km;
l _{3}for pole line, length is 18km;
l _{4}for cable joint line, cable length is 5km, and pole line length is 12km;
l _{5}for pole line, length is 30km;
l _{6}for cable, length is 8km.Load selects firm power load model, wherein
p=800
kW,
q=140
kVar.Now suppose feeder line
l _{1}there is singlephase earth fault, stake resistance 20 Ω in distance top 7 km A phase, fault angle is 90 °, and the moment occurs fault is 0.025s.The route selection flow process of fault feeder zerosequence current matrix principal component analysis (PCA) first principal component is utilized as shown in Figure 2 for this system.
When first intercepting 0.4ms after fault, the recorder data of each feeder line zerosequence current in window, as shown in figures 38, utilizes formula (1) to calculate the absolute value of each feeder line zerosequence current sum
i _{∑}=6.9A, for this system, determines threshold values by a large amount of emulation
i _{set}=100A is comparatively suitable.Cause
i _{∑}=6.9A<
i _{ set }=100A, therefore be judged to be feeder fault.
Then build zerosequence current matrix, the quantity due to system feeder line is 6, and therefore the data of zerosequence current sampled point mostly are 5 most.In zerosequence current recorder data as shown in figures 38, sample respectively in 0.0250s, 0.0251s, 0.0252s, 0.0253s and 0.0254s moment, obtaining zerosequence current matrix element structure zerosequence current matrix is:
Carry out principal component analysis (PCA) to abovementioned zerosequence current matrix using formula (3) to (7) again, each Principal component obtaining zerosequence current is as shown in table 1.
Wherein, in first principal component each element sign function value sgn (
p _{1}(
j))=(+111111),
j=1,2,3 ... 6.So, sgn (∑ sgn (
p _{1}(
j)))=(1).Obviously, sgn (
p _{1}(1)) × sgn (∑ sgn (
p _{1}(
j))) <0.So judgement feeder line
break down, consistent with hypothesis result, route selection is correct.
Embodiment 2: the distribution network systems of neutral by arc extinction coil grounding as shown in Figure 1, systematic parameter is identical with embodiment.Now suppose feeder line
l _{2}there is singlephase earth fault, stake resistance 20 Ω in distance top 5 km A phase, fault angle is 90 °, and the moment occurs fault is 0.025s.The route selection flow process of fault feeder zerosequence current matrix principal component analysis (PCA) first principal component is utilized still as shown in Figure 2 for this system.
When first intercepting 0.4ms after fault, the recorder data of each feeder line zerosequence current in window, as shown in Fig. 914, utilizes formula (1) to calculate the absolute value of each feeder line zerosequence current sum
i _{∑}=1.6A, and the threshold values of this system is set to by a large amount of emulation
i _{set}=100A.Because
i _{∑}=1.6A<
i _{ set }=100A, therefore be judged to be feeder fault.
Then build zerosequence current matrix, the quantity due to system feeder line is 6, and therefore the data of zerosequence current sampled point mostly are 5 most.In the zerosequence current recorder data such as shown in Fig. 914, sample respectively in 0.0250s, 0.0251s, 0.0252s, 0.0253s and 0.0254s moment, obtaining zerosequence current matrix element structure zerosequence current matrix is:
Carry out principal component analysis (PCA) to abovementioned zerosequence current matrix using formula (3) to (7) again, each Principal component obtaining zerosequence current is as shown in table 2.
Wherein, in first principal component each element sign function value sgn (
p _{1}(
j))=(+11+1+1+1+1),
j=1,2,3 ... 6.So, sgn (∑ sgn (
p _{1}(
j)))=(+1).Obviously, sgn (
p _{1}(2)) × sgn (∑ sgn (
p _{1}(
j))) <0.So judgement feeder line
break down, consistent with hypothesis result, route selection is correct.
By reference to the accompanying drawings the specific embodiment of the present invention is explained in detail above, but the present invention is not limited to abovementioned embodiment, in the ken that those of ordinary skill in the art possess, various change can also be made under the prerequisite not departing from present inventive concept.
Claims (3)
1. one kind utilizes the selection method of fault feeder zerosequence current matrix principal component analysis (PCA) first principal component, it is characterized in that: after the distribution network generation singlephase earth fault of neutral by arc extinction coil grounding, line selection apparatus starts, first calculate the absolute value of each feeder line zerosequence current sum in short timewindow after a failure, realize the judgement to busbar fault and feeder fault by this value and the magnitude relationship of setting threshold values; After being defined as feeder fault, then build each feeder line zerosequence current matrix and principal component analysis (PCA) is carried out to it, obtain each Principal component of zerosequence current matrix, and respectively the sign function of the sign function of each for first principal component element and first principal component each symbol of element function sum is taken advantage of; Finally reliably realize failure line selection according to the magnitude relationship making value and the null value taken advantage of.
2. the selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component according to claim 1, is characterized in that: the concrete steps of described selection method are as follows:
After A, generation singlephase earth fault, in short timewindow, calculate the absolute value I of each feeder line zerosequence current sum
_{∑}, and by this value and setting threshold values I
_{set}magnitude relationship realize to busbar fault and feeder fault judgement:
Work as I
_{∑}>I
_{set}time, be judged to be busbar fault;
Work as I
_{∑}<I
_{set}time, be judged to be feeder fault;
In formula: i
_{0j}k () represents the amplitude of its zerosequence current of feeder line when k sampled point being numbered j, j=1,2,3 ... N is the numbering of feeder line, and N is feeder line number; K=1,2,3 ... K is sampled point numbering, and K is zerosequence current data sampled point quantity; K<N;
B, according to the zerosequence current data of N bar feeder line on abovementioned K zerosequence current data sampled point, build N × K zerosequence current matrix i, and after carrying out principal component analysis (PCA) to it, the sign function of the sign function and first principal component each symbol of element function sum that obtain each element of first principal component is respectively sgn (P
_{1}(j)), sgn (∑ sgn (P
_{1}(j))); Wherein P
_{1}j () is the first principal component value after zerosequence current matrix principal component analysis (PCA), j=1,2,3 ... N is the numbering of feeder line, and N is feeder line number:
C, according to sgn (P
_{1}(j)) and sgn (∑ sgn (P
_{1}(j))) magnitude relationship determination failure line selection between product between the two and null value:
As sgn (P
_{1}(j)) × sgn (∑ sgn (P
_{1}(j))) < 0 time, judge that jth bar feeder line is as fault feeder.
3. the selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component according to claim 1 and 2, is characterized in that: when calculating each feeder line zerosequence current sum, the length of short timewindow is 0.4ms.
Priority Applications (1)
Application Number  Priority Date  Filing Date  Title

CN201310336150.5A CN103424669B (en)  20130805  20130805  A kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component
Applications Claiming Priority (1)
Application Number  Priority Date  Filing Date  Title

CN201310336150.5A CN103424669B (en)  20130805  20130805  A kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component
Publications (2)
Publication Number  Publication Date

CN103424669A CN103424669A (en)  20131204
CN103424669B true CN103424669B (en)  20160330
Family
ID=49649705
Family Applications (1)
Application Number  Title  Priority Date  Filing Date

CN201310336150.5A Active CN103424669B (en)  20130805  20130805  A kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component
Country Status (1)
Country  Link

CN (1)  CN103424669B (en)
Families Citing this family (13)
Publication number  Priority date  Publication date  Assignee  Title

CN103760462B (en) *  20140114  20160824  昆明理工大学  A kind of current temporary state amount classified analysis on major constituents direction protection method of band SSSC transmission line of electricity
CN103744002B (en) *  20140117  20160817  昆明理工大学  A kind of fault section recognition methods of cable based on current temporary state amount classified analysis on major constituentsline mixed power transmission line
CN103901323B (en) *  20140401  20160601  河南理工大学  A kind of faultline selecting method utilizing improvement oscillator system
CN104577999B (en) *  20150108  20180216  广西星宇智能电气有限公司  Bus bar protecting method and system based on transient zerosequence current feature
CN104635111B (en) *  20150123  20170825  云南电网公司楚雄供电局  A kind of distribution network failure based on fault moment Stransformation spectral characteristic starts method
CN104617566B (en) *  20150123  20170912  昆明理工大学  A kind of small current neutral grounding system singlephase fault based on the positive and negative area sum of residual voltage starts method
CN104880642B (en) *  20150512  20180511  昆明理工大学  A kind of alternating current circuit fault phaseselecting method based on patternrecognition
CN104993462A (en) *  20150630  20151021  昆明理工大学  Mode recognitionbased current transient state quantity direction protection method for power transmission line with unified power flow controller
CN105182175B (en) *  20150630  20180406  昆明理工大学  A kind of UHVDC Transmission Lines complete fibre guard method using polar curve fault current set of curves classified analysis on major constituents
CN105098740B (en) *  20150915  20171222  昆明理工大学  A kind of combined floodgate based on forward current traveling wave classified analysis on major constituents is to fault recognition method
CN106443352B (en) *  20161027  20190607  山东科技大学  A kind of method of neutral point ungrounded electric network singlephase earth fault line selection
CN110988590A (en) *  20191125  20200410  云南电网有限责任公司临沧供电局  PCASVM modelbased distribution network line selection method and system
CN111121943B (en) *  20191213  20210518  湖南师范大学  Zero point fault detection method and device, computer equipment and readable storage medium
Citations (4)
Publication number  Priority date  Publication date  Assignee  Title

FR2876187A1 (en) *  20041001  20060407  Airbus France Sas  Method and device for detecting an electric arc phenomenon on at least one electrical cable
CN101718833A (en) *  20091215  20100602  西南交通大学  Method of single end distance measurement of power transmission line malfunction based on traveling wave inherent frequency extraction
CN102095996A (en) *  20101204  20110615  西南交通大学  Malfunction phase selecting method of highvoltage transmission circuit based on natural frequency of travelling wave
CN102928731A (en) *  20121106  20130213  昆明理工大学  Power distribution network fault line selection method using zerosequence current full quantity Hough transformation
Family Cites Families (1)
Publication number  Priority date  Publication date  Assignee  Title

JPH0713652B2 (en) *  19870402  19950215  富士電機株式会社  Fault location method for parallel twoline transmission line

2013
 20130805 CN CN201310336150.5A patent/CN103424669B/en active Active
Patent Citations (4)
Publication number  Priority date  Publication date  Assignee  Title

FR2876187A1 (en) *  20041001  20060407  Airbus France Sas  Method and device for detecting an electric arc phenomenon on at least one electrical cable
CN101718833A (en) *  20091215  20100602  西南交通大学  Method of single end distance measurement of power transmission line malfunction based on traveling wave inherent frequency extraction
CN102095996A (en) *  20101204  20110615  西南交通大学  Malfunction phase selecting method of highvoltage transmission circuit based on natural frequency of travelling wave
CN102928731A (en) *  20121106  20130213  昆明理工大学  Power distribution network fault line selection method using zerosequence current full quantity Hough transformation
NonPatent Citations (1)
Title

数据挖掘及其在小电流接地选线中的应用;刘雪莉;《中国优秀硕士学位论文全文数据库（电子期刊）》;20051231;论文第40页5.2节 *
Also Published As
Publication number  Publication date

CN103424669A (en)  20131204
Similar Documents
Publication  Publication Date  Title

CN103424669B (en)  A kind of selection method utilizing fault feeder zerosequence current matrix principal component analysis (PCA) first principal component
CN103424668B (en)  A kind of continuous selection method of arc grounding fault utilizing the principal component analysis (PCA) of feeder line zerosequence current and evidence theory fusion
CN103474981B (en)  A kind of distribution network singlephase ground protection method based on the multistage differential transformation direction of zerosequence current
CN103267927B (en)  A kind of low current neutral grounding system fault route selecting method utilizing power frequency component wavelet coefficient fitting a straight line to detect
CN103197202B (en)  Distribution network fault line selection method based on wavelet coefficient correlation analysis in threephase breaking current component characteristic frequency band
CN100387999C (en)  Circuit fault directional detecting and protecting method for power supply system
CN103257304A (en)  ANN fault line selection method through CWT coefficient RMS in zerosequence current feature band
CN103245883A (en)  Power distribution network fault circuit selection method based on transient zerosequence current timefrequency characteristic vectors
CN104614638A (en)  Grounding line selection method for small current system
CN103018630A (en)  Singlephase earth fault transient line selection method of distribution network
CN103197203A (en)  Fault line selection method based on time domain waveform correlation analysis of threephase current breaking variable
CN103163430A (en)  Resonant grounding system fault line selection method by combining complex wavelets with ANN (artificial neural network)
CN105119255A (en)  Photovoltaic microgrid fault isolation method based on fault state
CN103163417B (en)  Unreal grounding identification method based on short time window and highlow frequency transient state energy ratio
CN104597378A (en)  Fault lineselection method of power distribution network containing DG based on transient state nonpowerfrequency zerosequence currents
CN103474980B (en)  A kind of power distribution network singlephase ground protection method based on transient power direction
CN102288875A (en)  Lowcurrent grounding wireselecting method
CN105759167A (en)  Wavelet neural networkbased distribution network singlephase short circuit line selection method
CN104360227A (en)  Substation cable outlet fault monitoring method based on traveling wave method and transient basic frequency method
CN103474974B (en)  A kind of distribution network singlephase ground protection method based on zerosequence current Sudden Changing Rate fitting a straight line direction
CN107315128A (en)  A kind of distributed earthing wireselecting method and system based on GOOSE
CN108054736B (en)  A kind of multiterminal flexible direct current power grid DC line protection method based on voltage pole wave
CN102928731A (en)  Power distribution network fault line selection method using zerosequence current full quantity Hough transformation
CN104375056A (en)  Substation cable outgoing line fault monitoring method based on voltage and current initial row waves
CN103323728B (en)  Based on singlephase earth fault and the Xuhanting oral solution recognition methods of whole wave energy Ratios
Legal Events
Date  Code  Title  Description

C06  Publication
PB01  Publication
C10  Entry into substantive examination
SE01  Entry into force of request for substantive examination
C14  Grant of patent or utility model
GR01  Patent grant
